P4 Indoor LED Module Guide – 320x160mm Panel Explained
In today's digital age, LED technology has revolutionized the way we display information and advertisements. Among the various LED modules available, the P4 indoor LED module stands out due to its exceptional features and versatility. This guide delves into the intricacies of the P4 indoor LED module, focusing particularly on the 320x160mm LED panel, and offers insights into its applications, benefits, and technical specifications.
What is a P4 Indoor LED Module?
A P4 indoor LED module is a type of display panel that uses surface-mounted device (SMD) technology to deliver vibrant, full-color visuals. The "P4" designation refers to the pixel pitch, which is 4mm. This pixel pitch is crucial as it determines the resolution and clarity of the display. The smaller the pixel pitch, the higher the resolution, making P4 modules ideal for indoor environments where viewers are relatively close to the screen.
Key Features of the 320x160mm LED Panel
- Pixel Pitch: 4mm
- Module Size: 320mm x 160mm
- Resolution: 80 x 40 dots
- LED Type: SMD 2121
- Brightness: 800 - 1000 nits
- Viewing Angle: 140° horizontal and vertical
- Power Consumption: Max 700W/m², Average 300W/m²
- Operating Temperature: -20°C to 60°C
Benefits of Using P4 Indoor LED Modules
High Resolution and Brightness
The P4 indoor LED module offers a high-resolution display with a pixel density of 62,500 pixels per square meter. This ensures crisp and clear visuals, making it perfect for detailed content display. The brightness level, adjustable up to 1000 nits, ensures visibility even in well-lit environments.
Versatile Applications
These modules are widely used in various indoor settings, including shopping malls, conference rooms, and entertainment venues. Their flexibility allows them to be integrated into video walls, providing seamless and immersive viewing experiences.
Durable and Reliable
With a lifespan of over 100,000 hours and a robust design that includes a pure black mask for high contrast, the P4 LED module is built for longevity. It also features a protection level of IP54, ensuring resistance to dust and minor water splashes.
Technical Specifications and Performance
Understanding the technical specifications of the P4 indoor LED module is crucial for making an informed purchase. Here are some detailed parameters:
- Driving Method: Constant current, 1/20 scan
- Control System Compatibility: Compatible with Linsn, Novastar, and Colorlight control systems
- Refresh Rate: ≥1920 Hz, ensuring flicker-free visuals
- Color Temperature: Adjustable between 5000K and 9300K
- Gray Scale and Display Color: 16-bit correction, displaying 16.7 million colors
Power and Connectivity
The module operates on AC 100-240V power supply and supports various input signals, including DVI, HDMI, and SDI. It also allows for easy connectivity with an Ethernet cable up to 100 meters or optical fiber up to 5 kilometers.
Installation and Maintenance
Easy Installation
The 320x160mm LED panel is designed for straightforward installation. It includes standard data and power cables, and the modules can be easily chained together, reducing the need for extensive cabling.
Maintenance and Testing
Before dispatch, each module undergoes a rigorous 72-hour aging test, which includes white balance and video aging tests. This process ensures that the LEDs are stable and reliable, minimizing the risk of failure post-installation.
Choosing the Right P4 Indoor LED Module
When selecting a P4 indoor LED module, consider the following factors:
- Batch Consistency: Purchase modules from the same batch to ensure uniform brightness and color across the display.
- Warranty and Support: Opt for modules with a warranty of at least two years and access to technical support.
- Compatibility: Ensure compatibility with existing control systems and infrastructure.
Conclusion
The P4 indoor LED module, particularly the 320x160mm LED panel, offers a blend of high resolution, brightness, and durability, making it a top choice for indoor display solutions. Whether for commercial or entertainment purposes, these modules provide a reliable and visually stunning platform for your content.
For those looking to invest in LED technology, understanding the specifications and benefits of the P4 module is essential. By choosing the right module and ensuring proper installation and maintenance, you can achieve an impressive and long-lasting display solution.
